8pcs 4 Pair CCTV Coax BNC Video Audio Power Balun Transceiver to CAT5e 6

CCTV BNC Video, Power, & Audio Baluns

Transfer video, power, and audio via Cat5e/Cat6 ethernet connections with these single channel passive video/power/audio baluns. This kit features one pair of transceiver units.

Features

• Quantity: 4 Pair (8pcs)
• 1-Channel Passive Video, Power, and Audio Transceiver (Pair)
• Power, Audio, and Video signals are routed via Cat5e/Cat6 Cable with RJ45 connectors
• Male BNC with extended mini-coax pigtails to pass video
• Male RCA connector to pass audio
• One balun has a male DC plug, and the other has a female DC jack for providing power
• Compatible Video Formats: NTSC, PAL, and SECAM
• Compatible with CVBS, TVI, HD-TVI, HD-CVI, and AHD
• No power required
• Exceptional interference rejection
• 60dB Crosstalk and Noise immunity
• Installs in seconds
• LED Lights indicating Power Input and Surge Protection
• Compact size for easy installation
• ROHS Compliant
• FCC Compliant

Technical Specifications

• Connector 1: RJ45 Female Ports
• Connector 2: BNC Male, RCA Male, DC input & output
• Frequency Response: DC to 8MHz
• Attenuation: 0.5dB
• CMRR (Common Mode Rejection Ratio): 60 dB
• Impedance for BNC: 75 ohms
• Impedance for RJ45: 100 ohms
• Material: ABS Plastic

Package Includes

• One (1) Balun with BNC, RCA, and Male DC Plug
• One (1) Balun with BNC, RCA, and Female DC Jack
